Labels Compatible with the iDPRT iE2X Label Printer
The labels in this category have been selected for use with the iDPRT iE2X label printer. The range includes direct thermal paper labels, paper thermal transfer labels and durable synthetic labels for more demanding applications.
Compatible label rolls must have an overall media width between 20mm and 60mm, a 25mm (1") core and a maximum outside diameter of 127mm (5"). The maximum printable width used for this category is 54mm.
Direct Thermal Labels
The iDPRT iE2X can print onto heat-sensitive direct thermal labels without using ink, toner or a thermal transfer ribbon.
Direct thermal labels offer a convenient and economical choice for relatively short- to medium-term applications, including:
- Shipping and address labels
- Barcode and QR-code labels
- Retail and price labels
- Temporary stock identification
- Food rotation and date labels
- Specimen and sample labels
- General office labelling
The printer must be configured for direct thermal mode when using these labels.
Paper Thermal Transfer Labels
Paper thermal transfer labels are printed using a compatible thermal transfer ribbon. Heat from the printhead transfers ink from the ribbon onto the label surface, producing a more durable and longer-lasting image than standard direct thermal printing.
These labels are suitable for applications such as:
- Product and packaging labels
- Stock and inventory identification
- Long-term barcode labels
- Warehouse identification
- Batch and date-code labels
- Retail and price labels
- Laboratory and sample identification
Wax ribbons are commonly used with standard thermal transfer paper labels. A wax-resin ribbon may be more suitable for coated papers or applications requiring greater resistance to rubbing and handling.
Synthetic Labels
Synthetic materials such as polypropylene and polyester provide greater durability than standard paper labels. Depending on the material, adhesive and ribbon selected, they can offer improved resistance to moisture, tearing, abrasion, oils, chemicals and temperature changes.
Synthetic labels can be used for:
- Asset and equipment identification
- Electrical and electronic components
- Laboratory and healthcare applications
- Bottles, containers and packaging
- Durable barcode tracking
- Manufacturing and industrial identification
- Labels exposed to moisture or frequent handling
Most synthetic labels require a compatible wax-resin or resin thermal transfer ribbon. The correct ribbon should always be matched to the label material and intended application.
Compatible iDPRT iE2X Roll Dimensions
Labels in this category are selected according to the following requirements:
- Printing method: direct thermal or thermal transfer
- Maximum print width: 54mm
- Overall media width: 20mm to 60mm
- Roll core diameter: 25mm (1")
- Maximum outside roll diameter: 127mm (5")
The overall media width includes the label and its backing paper. Because the backing paper is normally slightly wider than the label itself, you should measure the complete roll width rather than only the face of the label.
The printed design must remain within the maximum printable width of 54mm, even when the total backing-paper width is greater.
Choosing the Correct Labels
Choose direct thermal labels for ribbon-free printing and relatively short-term applications. Choose paper thermal transfer labels when the print must remain readable for longer or withstand additional handling.
For applications involving water, abrasion, oils, chemicals or outdoor exposure, a synthetic thermal transfer label may be the most suitable option. Always check the individual material specification to confirm that it provides the required level of resistance.
Before ordering, check the label dimensions, complete backing-paper width, core diameter and outside roll diameter.
If you are unsure which label or ribbon to order, please contact us with your required label size and details of the application. Our team will be happy to recommend a suitable combination.
